Description
RE650
AC2600 Wi-Fi Range Extender
- Superior Extended Range – Four fixed external antennas extend Wi-Fi coverage*
- 4-Stream for AC2600 Dual Band Wi-Fi – Simultaneous 800Mbps on 2.4GHz + 1733Mbps on 5GHz*
- 4×4 MU-MIMO** – Simultaneously transfers data to multiple devices for 4x faster performance
- Beamforming Technology – Send targeted Wi-Fi signal to individual devices for stronger connections
- Gigabit Ethernet Port – Provide faster wired connections to smart TVs, computers and gaming consoles
- Intelligent Signal Light – Helps to determine the best location for optimal Wi-Fi coverage by indicating the signal strength in the current placement
- AP Mode – create a new Wi-Fi access point to enhance your wired network with Wi-Fi capability
- TP-LINK Tether App – Easily access and manage your network using any iOS or Android mobile device
- Ultimate Compatibility – Extend the range of any Wi-Fi router or wireless access point***
| HARDWARE FEATURES | |
|---|---|
| Plug Type | US |
| Standards and Protocols | IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a |
| Interface | 1x 10/100/1000M Ethernet Port (RJ45) |
| Button | WPS Button, Reset Button, LED Button, Power Button |
| Power Consumption | 12W（max power consumption） |
| Dimensions ( W x D x H ) | 6.4x 3.4 x 1.6 in. (163 x 86 x 40mm) |
| Antenna | 4x external |
| WIRELESS FEATURES | |
|---|---|
| Frequency | 2.4GHz & 5GHz(11ac) |
| Signal Rate | 5GHz:Up to 1733Mbps 2.4GHz:Up to 800Mpbs |
| Reception Sensitivity | 5GHz： 11a 6Mbps:-96dBm@10% PER 11a 54Mbps: -78dBm@10% PER 11ac HT20 mcs8: -69dBm@10% PER 11ac HT40 mcs9: -66dBm@10% PER 11ac HT80 mcs9: -63dBm@10% PER 2.4GHz 11g 54M: -79dBm@10% PER 11n HT20 mcs7: -77dBm@10% PER 11n HT40 mcs7: -74dBm@10% PER |
| Wireless Modes | Range Extender/Access Point |
| Wireless Functions | Wireless Statistic Concurrent Mode boost both 2.4G/5G WiFi band High Speed Mode for great speed for HD Gaming and video Access Control LED Control Domain Login Function |
| Wireless Security | 64/128-bit WEP WPA-PSK / WPA2-PSK |
| Transmission Power | <20dBm(2.4GHz) <23dBm(5GHz) |
| OTHERS | |
|---|---|
| Certification | FCC, RoHS |
| Package Contents | AC2600 Wi-Fi Range Extender RE650 Quick Installation Guide |
| Box Dimensions (W X D X H) | 7.9 x 4.9 x 3.8in. (202x 125 x 97mm) |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
